PV POLYCRYSTALLINE SOLAR MODULE 200Wp, 24VDC, Dimensions: 1640×680×35 mm, 15kg

Product description

🎨 Design & Style

Polycrystalline solar module with a classic blue hue, characteristic of polycrystalline cells.
The frame is made of anodized aluminum, ensuring strength and resistance to weather conditions.
Standard rectangular shape, suitable for various mounting configurations.
The front is covered with tempered glass for maximum protection.

📏 Dimensions & Installation

Dimensions: 1640 mm (length) x 680 mm (width) x 35 mm (thickness).
Weight: 15 kg, facilitating installation.
Standard mounting points, compatible with most solar panel mounting systems.
Designed for stationary installation on roofs, ground, or other suitable structures.

⚙️ Technical Specifications

Type: Polycrystalline PV Solar Module
Power: 200 Wp
Voltage: 24 V DC
Maximum Power Voltage (Vmp): 25 V
Maximum Power Current (Imp): 8 A
Open Circuit Voltage (Voc): 30.25 V
Short Circuit Current (Isc): 8.8 A
Temperature Coefficient (αPm): -0.43%/°C
Temperature Coefficient (αVoc): -0.33%/°C
Temperature Coefficient (αIsc): +0.04%/°C
Junction Box: IP65 (dust and splash proof)
Product Code: SRP200

✔️ Advantages

High efficiency and reliability for clean energy production.
Durable construction designed for a long service life.
Easy installation thanks to standard dimensions and weight.
Resistance to external conditions ensured by the IP65 junction box protection.
Optimal solution for residential and commercial solar installations.

Product characteristics

Juction box	IP65
Voltage (Volt)	24V DC
Temperature Coefficient αPm	-0,43% / °C
PV Solar Module Type	Polycrystalline
Maximum Power Voltage (Vmp)	25V
Maximum Power Current (Imp)	8A
Power	200 W
Short Circuit Current (Isc)	8,8A
Open Circuit Voltage (Voc)	30,25V
Temperature Coefficient αVoc	-0,33% / °C
Temperature Coefficient of Isc	+0,04% / °C

143.28 € / 280.23 лв.

Stock in Bulgaria

Out of stock

Stock in EU

Upon request

Product code: SRP200

Information about technical characteristics, equipment, country of origin and appearance of the product is for reference only and is based on the latest available information from the manufacturer.
