PV POLYCRYSTALLINE SOLAR MODULE 150Wp, 12VDC, Dimensions: 1480×680×35 mm, 11.5kg

Product description

🎨 Design & Style

Polycrystalline solar module with a classic blue hue characteristic of polycrystalline cells.
Anodized aluminum frame for strength and weather resistance.
Standard rectangular design, suitable for various mounting types.

📏 Dimensions & Installation

Dimensions: 1480 mm (length) x 680 mm (width) x 35 mm (thickness).
Weight: 11.5 kg, facilitating installation.
Designed for 12V DC systems.
Compatible with standard solar panel mounting systems.

⚙️ Technical Specifications

Power: 150 Wp
Type: Polycrystalline
Maximum Power Voltage (Vmp): 17.8 V
Open Circuit Voltage (Voc): 21.5 V
Maximum Power Current (Imp): 8.43 A
Short Circuit Current (Isc): 9.27 A
Temperature Coefficient (αPm): -0.43%/°C
Junction box: IP65

✔️ Advantages

High efficiency and reliability for solar energy production.
Durable construction designed for a long service life.
Versatile design suitable for residential, commercial, and industrial applications.
Easy to install and integrate into existing systems.

Product characteristics

Juction box	IP65
Temperature Coefficient αPm	-0,43% / °C
PV Solar Module Type	Polycrystalline
Temperature Coefficient αVoc	-0,33% / °C
Temperature Coefficient of Isc	+0,04% / °C
Voltage (Volt)	12V DC
Maximum Power Voltage (Vmp)	17,8V
Maximum Power Current (Imp)	8,43A
Power	150 W
Short Circuit Current (Isc)	9,27A
Open Circuit Voltage (Voc)	21,5V

110.40 € / 215.92 лв.

Stock in Bulgaria

Out of stock

Stock in EU

Upon request

Product code: SRP150

Information about technical characteristics, equipment, country of origin and appearance of the product is for reference only and is based on the latest available information from the manufacturer.
