Compact single-pole miniature circuit breaker (MCB) with modern industrial light-grey housing.
Clear lever indication (red/green ON/OFF) and large labeling window.
Standard DIN rail mount with only 1 module width (18 mm) for neat panel layout.
📏 Dimensions & mounting
Width: 1 module (17.8 mm)
Height: 90 mm, depth: 70 mm
Mounting on 35 mm DIN rail (TH35 standard)
Tool-free snap-on mounting, top and bottom cable connection.
⚙️ Technical specifications
Poles: 1P (single pole)
Rated current: 63 A
Tripping curve: B (3-5 In, suitable for general lighting and socket circuits)
Breaking capacity: 6 kA
Voltage: 230/400 V AC
Utilization category: AC
Standard: IEC/EN 60898-1
Temperature range: -25°C to +70°C
✔️ Advantages
High 6 kA breaking capacity – reliable protection even under short-circuit conditions.
B63 curve – perfect for residential installations, lighting, and power outlets.
Ultra-compact size – saves valuable space in electrical panels.
Bi-directional connection (top or bottom) for easier installation.
Long service life and proven reliability from a trusted manufacturer.
3.17 € /6.20 лв.
Minimum order from: 12 pcs.
Stock in Bulgaria
In stock
Delivery 2-4 working days
Stock in EU
Upon request
Product code:DY02060397
Information about technical characteristics, equipment, country of origin and appearance of the product is for reference only and is based on the latest available information from the manufacturer.
